● Setting Character Height and Character Orientation 3-36
Product speed matching
● When printing is conducted with this feature activated, the character
width is maintained irrespective of print target transport speed changes.
Pulse rate division Factor
● Specifies the pulse rate division Factor that determines the intervals at
which the encoder signal is to be recognized.
● The selectable setting ranges from 1/1 to 1/999.
● When a setting of 1/1 is selected, no pulse rate division Factor is effected.
● This feature cannot be activated if the product speed matching feature is
disabled.
High-speed printing
● Set the high-speed printing format. See "3.10 Setting high-speed printing"
for details.
Calendar offset
● Specifies whether the "from today" or "offset from yesterday" option is to
be selected for calendar month/year offset determination.
Day of week character
● Set the type of character to be printed for calendar (day of the week)..
Mon Tue Wed Thu Fri Sat Sun
1 to 7
1234567
A to G
ABCDE FG
Registered character
C1 C2 C3 C4 C5 C6 C7
The last 7 chracters are used for user pattern characters.
9
10
11
12
13
Shut
down
Manual
Back
Show
cursor
←
→
Prev.
dis-
paly
Next
dis-
paly
Decre-
ment
Incre-
ment
123 456789
Print specifications Status: Ready
0
[ ] (0: 1:Enable)
Pulse rate div. Factor [ 0 0 1 ] (1/1~1/999 Enter denominator.)
High-speed print [ 0 ] (0: 1:NM 2:QM)
Calendar offset [ 1 ] (1: 2:from today)
Day of week char. [ 1 ] (1: 2:A-G 3:User pattern)
0
Product speed matching
Disable
HM
offset from yesterday
1-7
The “Print specifications” fourth screen
