5-18 ● Calibrating the Touch Screen Coordinates
From the print description screen, press Menu .
The menu then opens.
1
While the menu is displayed, press Auxiliary function .
The auxiliary function menu then appears.
2
5.4 Calibrating the Touch Screen Coordinates
● The procedure for adjusting the difference between the touch panel and on-screen
coordinate positions.
Shut
down
Manual
Back
Manage messages
Aux. function menu Status: Ready
Create user
pattern
Calibrate touch
screen coordinates
Copy data Select Languages
Edit Standard
pattern
HOME
Com=0
Press Calibrate touch screen coordinates .
The touch screen coordinates screen then opens.
3
Carefully touch the intersection of
the crosshairs.
Touch screen coord. Status: Ready
Com=0
Press the + mark at the upper left-hand corner.
The + mark appears at the bottom right.
4
Carefully touch the intersection of
the crosshairs.
Touch screen coord. Status: Ready
Com=0
Menu
Maintenace
Auxiliary
function
Operation
management
Show fault
/Warning
Environment
setup menu
When HOME is
pressed, the system
returns to the print
description screen.
Press the + mark at the bottom right.
5
