3-7 ● Setting Print Format
Inter-character space
● The space between characters can be set.
● The following settings are selectable.
Character size Inter-character space
5×5 0 to 3
5×8 or 5×7 0 to 3
9×8 or 9×7 0 to 7
7×10 0 to 3
12×16 0 to 4
18×24 0 to 6
24×32 0 to 8
3
● To perform "interlaced" printing in the case of using dedicated characters, the
inter-character space of all the printing items should be 1 dot.
● The inter-character space of the printing items having dedicated characters
should be 1 dot.
(See Section "3.3.2 Printing dedicated characters".)
Increased width
● The width of characters can be magnified.
● The selectable magnifications are from 1 to 9.
Bar code
● The bar code type can be specified.
● One bar code type can be selected.
● The following types are selectable.
Type Available characters
Code 39
(C39)
0 to 9, A to Z, space, +, -, /, . (period), $, %
ITF 00 to 99
NW-7 0 to 9, +, -, /, .(period), :, $
EAN-13 0 to 9
Data matrix
(DM)
All Alphabets, numerals, symbols and FNC1
Code128
(C128)
(Code set B) All Alphabets, numerals, symbols and FNC1
(Code set C) 0 to 9, FNC1
● Bar code type changes are simultaneously applied to all items for which bar
code setup has been cimpeleted.
● For DM and Code 128, number of barcodes which can be set is four.
When multiple barcodes are to be set, insert print item to which no barcode
has been set between them.
● For Code 39, ITF, NW-7, EAN-13, DM and Code 128 barcode can be set to
print items to which calendar or count has been set. However, barcode cannot
be set if replacement of calendar, zero suppression or characters which cannot
be used have been set. In these cases, the characters will be replaced with
invalid characters.
● Input keybord appear only valid characters.
If the setting range is
exceeded by a
character size change,
the closest acceptable
value will be
employed.
For a Inter-line method,
see "Precautions to be
observed when
changing the printings,
print format, or line
count setup data"
(See section 2.1.3,
Operation for Modify-
ing the Setting Con-
tents.)
The available
functions and printable
line count and
character sizes vary
from one model to
another.
See Section 11.1,
Printer Specifications.
