● Transmission Sequences 6-19
6.4.2-4 Character codes
(1) 2-byte code (number of communication bytes: 1-byte mode)
● One character
SI
High-order
byte
Low-order
byte
SO
SI
High-order
byte
Low-order
byte
High-order
byte
Low-order
byte
High-order
byte
Low-order
byte
SO
High-order
byte
Low-order
byte
ASCII ASCII SI
High-order
byte
Low-order
byte
High-order
byte
Low-order
byte
SO ASCII
ASCII ASCII
High-order
byte
Low-order
byte
High-order
byte
Low-order
byte
ASCII
● Two or more characters
(2) 2-byte code (number of communication bytes: 2-byte mode)
(3) Mixture of ASCII and 2-byte codes
(4) Mixture of ASCII and 2-byte codes
(number of communication bytes: 2-byte mode)
(1) Text
For message numbers 001 to 150
ESC Header 56H Hundreds position Tens position Units position
Print data message number
* For use only with message numbers 01 to 99, a call can be made by the following
method.
In this case, the data of the hundredth digit is not required.
ESC Header 26H Tens position Units position
(2) Print data message number
● An already saved print data number is to be designated as the print data message
number.
● The message number range is from 01 to 150.
● The message number is expressed by a combination of three ASCII codes.
Message
number
ASCII code
Message
number
ASCII code
01 (30)H, (30)H, (31)H 100 (31)H, (30)H, (30)H
02 (30)H, (30)H, (32)H 101 (31)H, (30)H, (31)H
...... ...... ...... ......
89 (30)H, (38)H, (39)H 149 (31)H, (34)H, (39)H
99 (30)H, (39)H, (39)H 150 (31)H, (35)H, (30)H
6.4.3 Print Data Recall / Transmission
