7-9 ● Ink Replacement
When the predetermined period of time elapses,
the following operating guidance appears on the display.
6
*1 Clean the connection at the end of the recovery tube sufficiently with the
makeup ink, and then connect it as it originally was.
*2 To prevent the recovery tube from becoming crimped, be careful not to let it
cross another tube.
Circulation control Status: Stop
Start/
Continue
Process : Ink replacement
Com=0
Proc.time: Approx. 4 minutes
Proc. status: In progress
Abort
Connect a recovery tube to
the main ink tank as before.
Press [Start/Continue].
Operating guide
Press the Start/Continue key.
The following operating guidance appears.
7
Circulation control Status: Stop
Start/
Continue
Process : Ink replacement
Com=0
Proc.time: Approx. 4 minutes
Proc. status: In progress
Abort
Empty the ink reservoir and then fill it.
Cap it and return it to the storage posi-
tion. Press [Start/Continue].
Operating guide
Press the Start/Continue key.
The screen shown below then opens and the ink in the printer drains away via
the drainage tube.
5
Circulation control Status: Stop
Process : Ink replacement
Com=0
Proc.time: Approx. 4 minutes
Proc. status: In progress
Abort
● To abort the sequence, press the Abort key. Then, follow the on-screen
instructions to return the recovery tube to its original position and press the
Start/Continue key . You are then returned to the "Circulation control"
screen.
● When you have aborted the sequence, perform the procedure from 1 again.
* When aborting the operation, be sure to return the recovery tube to its
original position.
Ink drainage
Ink rep.
Ink refill
Ink drainage
Ink rep.
Ink refill
Ink drainage
Ink rep.
Ink refill
