● Maintenance 12-2
Air filter replacement procedure
Loosen the knob and remove the air filter cover.
1
Air filter cover
Knob
Air filter
Remove the air filter, and place a new filter, making sure the
orientation is correct.
2
Air filter
Red Mark
(The red mark side is the
inside of the printer.)
(1) First insert the top of air filter. (2) Place the bottom of air filter on the guide.
To Next Page
