PROG.MIX cont.
1. From the model menu, scroll to highlight
“PROG.MIX” and press the jog dial once to
enter the programmable mix menu.
2. Scroll to highlight the mix to be congured and press the
jog dial to activate the selection.
3. Rotate the jog dial to select ACT (activate),
then press the jog dial to conrm your selection and
activate the sub-menu for the selected mix.
4. Scroll to select the master/slave eld and
press the jog dial to activate the menu.
5. Scroll to select the master function eld (left eld) and press
the jog dial to activate the menu.
6. Scroll to select the desired function to be the master function
for the mix (THRO, RUDD, GEAR. etc.) and press the jog dial to
conrm your selection.
7. Scroll to select the slave function eld (right eld) and press
the jog dial to activate the menu.
8. Scroll to select the desired function to be the slave function
for the mix and press the jog dial to conrm your selection.
Press the back button to return to the programmable mix sub-
menu.
Example: Let’s say you want to control your ailerons as  aps using the one of the slider switches but you
don’t want to have the slider active all the time in case you accidentally bump it. You can assign the slider
to your virtual channel and then P-mix that channel to the aileron servos. Since you have the option to
have the P-mix activated with a switch so that the slider will only be active when the switch is in the on
position. While this is just one example there can be many other uses so if you run into a situation where
you cannot get the results you are looking for through the normal mixing consider using the virtual
channel along with a P-mix.
9. Scroll to highlight the “RATE” eld and press the jog dial to
activate the menu.
10. Use jog dial to select “L/U” (Left/Up) “R/D (Right/Down) and
press button to enter. .
11. Scroll to select the master function eld. Rotate the jog dial
to increase (clockwise) or decrease (counter-clockwise) the
desired left, right(AILE,RUDD) or up, down(ELEV) servo
movement for the lave function.
Press jog dial to conrm your input.
12. When changing only “L/D” (Left/Up) direction or servo
movement, use the jog dial to select “L/D” (Left/Up) and
press to conrm the selection.
13. Scroll to select the master function eld. Rotate the jog dial
to increase (clockwise) or decrease (counter-clockwise) the
desired left(AILE,RUDD) or up (ELEV) servo movement
for the lave function.
Press jog dial to conrm your input.
14. When changing only “R/D” (Right/Down) direction or servo
movement, use the jog dial to select “R/D (Right/Down) and
press to conrm the selection.
15. Scroll to select the master function eld. Rotate the jog dial
to increase (clockwise) or decrease (counter-clockwise) the
desired right (AILE,RUDD) or down (ELEV) servo movement
for the lave function.
Press jog dial to conrm your input.
16. Press the back button to prog. mix sub menu..
17. Scroll to highlight “EXP”eld and press the jog dial to
activate the menu.
PROG.MIX cont.
