HITEC Flash 8 User Manual

72 73
11. Scroll to highlight “EXP” eld, and press the jog dial to
activate the menu.
12. Rotate the jog dial to input the desired exponential travel of
the rudder when reacting to this mix. The setting does not
aect exponential travel when yaw commands are given.
13. Scroll to highlight “OST” eld, and press the jog dial to
activate the menu.
14. Rotate the jog dial to set the increase/decrease amount of
Oset for rudder servo/ Press the jog dial to conrm your
input.
15. Scroll to highlight “SPEED” eld, and press the jog dial to
activate the menu.
16 Rotate the jog dial to set the speed on the rudder for aileron
movement. Press the jog dial to conrm your input.
This setting does not activate when controlling the rudder.
17 Scroll to highlight “TRIM” eld, and press the jog dial to
activate the menu.
18. Scroll to select “OFF” or “ON”, then press jog dial to conrm
your input.
“ON” will allow this mix to activate for aileron trim adjustment.
“OFF” will not activate the change of aileron trim.
19. Scroll to the “S/W” eld and press the jog dial twice to
activate the menu.
20. Scroll to select a switch to activate the mix. Press the jog dial to conrm your selection.
a. If you choose the “NULL” option, the mix will remain
active at all times for this model.
b. If you choose a switch:
- The switch position menu will appear. Scroll to highlight the
switch position that you will use to enable the mix.
Press the jog dial to conrm your selection.
- Scroll to select “ON” and press the jog dial to conrm your
selection. If you toggle the selected switch, the eld in the
top right corner of the screen will indicate when the mix is active.
Aile>Rudd cont. Aile>Rudd cont.
21. Set up accordance with Flight Condition
- The upper right eld of the menu displays which ight
condition is currently active and will be programmed.
- Scroll to the Flight Condition eld and press the jog dial to
activate the menu.
- Choose the desired ight condition and press the jog dial to conrm your selection.
22. Press the back button to return to the model function menu.
To disable the aileron-rudder mix:
1. Scroll to highlight the “MIX” eld in the aileron-rudder mix
menu and press the jog dial to activate the menu.
2. Select “INH” (inhibit) and press the jog dial to conrm
your selection.
3. Press the back button to return to the model function menu.
You may also select a ight condition in this menu by activating the desired ight condition.
Elev>Camb
The Elevator-to-Camber Mix allows the model to drop and raise the trailing edge of the wing control
surfaces in conjunction with elevator inputs. This function is not valid for the “1AILE” or “ELEVON” wing
types unless aps are also present. If using a “1AILE + 1FLAP”, “1AILE + 2FLAP”, “ELEVON + 1FLP”, or
“ELEVON + 2FLP” wing type, do not congure any settings for the “AILE” function. Congure only ap
servo movements.
To congure an elevator-to-camber mix:
1. From the model menu, rotate the jog dial to highlight
“ELEV>CAMB” and press the jog dial once to enter the
activation menu.
4. Scroll to the function eld (“AILE” or “FLAP”). If “AILE” is not
the current function, press the jog dial to activate the menu.
Otherwise, skip to step.
5. Scroll to select “AILE” and press the jog dial to conrm your
selection.
2. Press the jog dial again to activate the menu.
3. Rotate the jog dial to select “ACT” (activate), then press the jog
dial to conrm your selection and activate the elevator-
camber mix menu.
TipTip
Tip
- Repeat steps 4-18 to dene the settings for each ight condition.
