Hologic Faxitron Path - Compliance Requirements and Safety Measures

FAXITRON PATH USER MANUAL | HOLOGIC | REVISION 024
S
ECTION
C
ompliance
a
nd Safet
y
6
6 - 2
Requirements | Faxitron Path Compliance
Emission Limits
Radiation emitted from the Faxitron Path unit does not exceed an exposure of 0.1 milli-
Roentgen (mR) per hour at any point 5 centimeters (cm) outside the external surface. Fo
r
countries requiring emission values measured at 10 cm from the external surfaces, the
radiation does not exceed 0.1 mR per hour at 10 cm.
Safety Interlocks
Faxitron Path Specimen DR system has two safety interlocks on the specimen door.
Start Button
Following interruption of X-ray generation by the safety interlocks, the Start button on the front
panel will resume X-ray generation when ready.
Key Actuated Control
Key Lock switch located on the front panel, which requires a key to be inserted and turned
clockwise to the 3 o’clock position in order to provide power to the cabinet system. The key is
captive in the “ON” position.
Emergency Stop Button
The Emergency Stop button on the Faxitron Path front panel is available to terminate the
generation of X-rays. This is in addition to the safety interlocks on the system doors.
X-ray Generation Indicators
The Faxitron Path has an X-ray On indicator light on the front panel and graphical use
r
interface, and also produces an audible tone when generating x-rays.
Power Ratings
100-240 50/60 HZ 200 W MAX.
Heat Output
500 BTU/hr MAX.
LASER LOCATOR
The Faxitron Path utilizes a pair of laser generated lines to aid in positioning samples in the
middle of the imaging field.
Laser Parameters
Lasers comply with IEC 60825-1:2007
Class 2 Laser Products
Wavelength: 670nm
Peak Power: 2mW
Line Width: 1mm Typical
Beam Divergence: 85º Typical
The lasers require no assembly.
There is no authorized operator maintenance on the lasers. The lasers are to be serviced only
by a Hologic Authorized Representative.
LASER ELECTRICAL PARAMETERS
Operating Voltage: Red: 3-6VDC
Black: Ground
Operating Current: 50mA Typical
80mA MAX
6.1.0
Compliance
Requirements and
Safety Measures
