GWF-7075 Addressable Fire Alarm Control Panel Manual — P/N LS10147-002GF-E:E 06/11/2019 13
Section 3: Installation Instructions Criteria
This section of the manual is intended to help you plan your tasks to facilitate a smooth installation. Please read this section thoroughly,
especially if you are installing a GWF-7075 panel for the first time.
3.1 Inventory
When you receive the GWF-7075 shipment, be sure to check and verify that the following components were included in the shipment.
Check that all the parts are included in the shipment. The shipment consist of one of each of the following:
• main circuit board with display
• backbox with door
• plastic bag containing two keys, screws, cables, and ten 4.7K ohm end-of-line resistors
• manual
3.2 Environmental Specifications
It is important to protect the GWF-7075 control panel from water. To prevent water damage, the following precautions should be FOL-
LOWED when you install the units:
• Intended for indoor use in dry locations only.
• Do not mount directly on exterior walls, especially masonry walls (condensation).
• Do not mount directly on exterior walls below grade (condensation).
• Protect from plumbing leaks.
• Protect from splash caused by sprinkler system inspection ports.
• Do not mount in areas with humidity-generating equipment (such as dryers, production machinery).
When you select a location to mount the GWF-7075 fire alarm control panel, install the unit in a location where it will NOT be exposed
to temperatures outside the range of 0°C-49°C (32°F-120°F) or humidity outside the range of 10%-93% at 30°C (86°F) non-condensing.
3.3 Software Downloads
To supply the latest features and functionality in fire alarm and life safety technology to our customers, the Manufacturer makes fre-
quent upgrades to the embedded software in the products. To ensure that you install and program the latest features, the Manufacturer
strongly recommend that you download the most current version of software for each product prior to commissioning any system. If you
have questions about the software and the most recent version for a specific application, contact Technical Support . To download the
HFSS Honeywell Fire Software Suite, you must obtain Customer Training from a Certified Trainer is available at
www.gamewell-fci.com.
Electrical Specifications
Table 3.1 list the terminal block on the GWF-7075 as well as a description of the each individual terminal and their respective electrical
rating. For the location of the terminals, refer to Figure 3.2. See also Section 4 for installation.
* Regulated NAC application. When programmed for releasing, NAC are Special Application.
Terminal No.
Label
Description
Rating
G r o u p I n d i v i d u a l V o l t a g e C u r r e n t
Terminal Block 3 TELCO 1 RING Phone Line 1 Telco Ring
TIP Phone Line 1 Telco Tip
PHONE 1 RING Phone Line 1 Phone Ring
TIP Phone Line 1 Phone Tip
TELCO 2 RING Phone Line 2 Telco Ring
TIP Phone Line 2 Telco Tip
PHONE 2 RING Phone Line 2 Phone Ring
TIP Phone Line 2 Phone Tip
Terminal Block 2
RELAY 1
NO Normally open relay contact 27.4 VDC 2.5 A, resistive
COM Common terminal
NC Normally closed relay contact
RELAY 2 NO Normally open relay contact 27.4 VDC 2.5 A, resistive
COM Common terminal
NC Normally closed relay contact
Terminal Block 2
TROUBLE NO Normally open relay contact 27.4 VDC 2.5 A, resistive
COM Common terminal
NC Normally closed relay contact
SLC IN – Used for Class A installations 32 VDC 100 mA
+
SLC OUT – SLC terminals 32 VDC 100 mA
+
SLC PROG – Used for programming SLC
Detectors
32 VDC 100 mA
+
SBUS – SBUS Power 27.4 VDC 0.5 A
+
A SBUS Communication 5 VDC 100 mA
B
NAC1* – Notification Appliance
Circuit/Auxiliary power
27.4 VDC 1 Amp NAC or
Aux power +
NAC2* – Notification Appliance
Circuit/Auxiliary power
27.4 VDC 1 Amp NAC or
Aux power +
P8 EXT. Comm
Cellular Connection
B Cellular Transmitter input
A
S+ 55 mA, 95 mA
S-
Table 3.1 Terminal Descriptions and Electrical Specifications
