60
Honeywell 35 Series IP Cameras User Guide
IRIS: Click and to adjust the IRIS setting.
Speed [1-8]: Select the movement speed for camera view. The speed range is 1 to 8 and
the default setting is 5.
Home Position Setup
SET: Click to set the current position as the home location.
RESTORE: Click to restore the home position to default.
Preset Management
Click Remove all to delete all the preset list.
Click to go to this preset.
Click to replace this preset with current position.
Click to remove the preset.
Preset point 80~115 are reserved for special presets. And calling special preset 103
will run wiper once.
Scan Management
Go to Setup PTZ Setup Scan.
Figure 39 Scan Settings
: Click the buttons to move the video image up/right/down/left/45-degree tilt
and click to return to the home location.
ZOOM: Click to zoom out the video image or click to zoom in the video image.
