3. Operating modes - overview
The evaluation unit offers various operating modes depending on the grade of extension of the
system and the requirements:
This operating mode enables the extension of already existing IK2 systems or the replacement of
components. For this purpose, the evaluation unit provides an IK2-compatible interface for
connecting random IK2 switching device (IK2 operating unit or IK2 block lock).
With evaluation unit firmware V03.xx upwards, reader at RS-485 Bus is also possible (for
types see Table in Chapter 4.).
The IK3 mode is the preferred operating mode. The full extent of the function is only possible in
this mode.
Switching devices: Up to 4 readers at RS-485 Bus (for types see Table in Chapter 4.).
As with IK3 mode, up to are supported . This is
equivalent to eight independent switching devices with individual authorizations.
Therefore, using the extended IK3 mode up to 8 "radio doors” can be equipped with an access
control function (for details see Chapter 2.4).
!
!
!
IK2 compatibility mode
IK3 mode
Extended IK3 mode
eight Trafficpoints RS-485 additionally
one
one
Possible operating modes depending on the grade of extension:
ICP/EU Firmware WINFEM Firmware WINFEM Firmware WINFEM
MB8/16/100, HB48 from V05.03 from V03.xx
MB256 from V04.xx from V03.xx
MB256 plus from V01.xx
Advanced
from V01.xx
from V03.xx from V06.xx
MB48 from V06.xx
Advanced
from V01.xx
MB100.10/
HB24 / 48.10
from V04.xx from V04.xx
MB100.10/
MB24 / MB48
from V12.xx
Advanced
from V12.xx
IK3 EU BUS-2 from V01.xx from V04.xx from V11.xx
Advanced
from V12.xx
only IK2 mode IK2 or IK3 mode
IK2 or
extended IK3 mode
