Honeywell IDENT KEY 3

59Mounting and Connection Instructions IK3 Evaluation Unit BUS-2
JP14
DB1
ST23
JP14
ST5
ST4
ST19
ST21
ST2
ST1
ST3 ST20 ST10
ST9
0V
ST13ST11 ST12
ST18
Rel 2
ST14
12k1
0 V
Must be plugged
on left
(for actuation Rel 1)
Impulse
controlled
door strike
Monitoring
contact
(to ST3)
No-load current
door strike
(for IDS or AC)
Load current
door strike
(for IDS or AC)
Armature contact
(Only for DS with
additional armature
contact "AC")
see IDS instructions
U_ext.
NCC M NOC
1=NCC
2=NOC
1M2 1M2
Monitoring
contact
(to ST3)
Monitoring
contact
(to ST3)
U_ext (DC or AC)
U_ext (DC or AC)
(only for IDS)
AC - Release button
Rel 2Rel 1
If the door strike
monitoring contact is
used, it should be
connected to a common
bolt switching group
(AND- function).
Door strike
monitoring contact
Bolt switching
contact
Door strike monitoring contact
Door strike armature contact
0 V
ST12ST11
