Mounting and Connection Instructions IK3 Evaluation Unit BUS-2
DB1
DB1
0 V
Manway
occupied
Other door open
Status indication
(see )9.7.3
Presence
monitorung
e.g. security mat
NC (normally closed)
Shield
Shield
Release
Data
Presence control
AC-Release button
(if required)
EU 1
EU 2
AC-Release button
(if required)
For all other connections (operating units, contacts, door
strikes, blocking elements), see Chapter 9.
Release
Data
Manway
occupied
Other door open
Status indication
(see 9.7.3)
ST11
ST14
ST14
ST10
ST23
ST12
ST13
ST18
ST5 ST4
ST21 ST2
ST1
ST3 ST20
ST19
ST10
ST23
ST12
ST13
ST18
ST5 ST4
ST21 ST2
ST1
ST3 ST20
ST19
ST11
0 V
0 V
0 V
0 V
ST9
ST9
