displayed at (2).

Fig. 3.18.2 Trouble Message Window

(3) Message selection button

When you press the button, the screen as shown in the Figure 3.18.3 will appear and you

can allocate the message.

Fig. 3.18.3 Trouble Message List

(4) Button to input the delay time for the trouble message

If you set the delay time, the trouble output and message will be displayed after the set

period of time when the trouble input is received. The delay time setting range is 0 ~ 99

seconds.

FAN EOCR FAULT

CLEAR

WATER VALVE FAULT

CLEAR

Trouble message

list sequence No.

FAN EOCR FAULT !

EMERGENCY STOP !

EDIT

WATER VALVE FAULT !

PRESSURE FAULT !

TROUBLE CH1 !

TROUBLE CH2 !

TUNING STOPPED CH1 !

TUNING STOPPED CH2 !

PROGRAM NAME

TRBL 0

EXIT

TROUBLE MESSAGE

12 .59 .00

03-02 WED

SET

▲ ▼

: FAN EOCR FAULT !
