54 MODBUS-GW Installation and Operation Manual — P/N LS10015-000NF-E:C2 4/30/2019
System Troubles
35031
0 Reserved 8 Reserved
1 Reserved 9 Reserved
2 Reserved 10 Reserved
3 Reserved 11 Reserved
4 Reserved 12 Reserved
5 Reserved 13 Reserved
6 Reserved 14 Reserved
7 Reserved 15 Reserved
35032
0 Reserved 8 NO POWER SUPPLY INST
1 Reserved 9 LOOP 1-2 COMM FAILURE
2 LINK PROTECTOR PRIMARY STATUS 10 LOOP 3-4 COMM FAILURE
3 LINK PROTECTOR SECONDARY STATUS 11 LOOP 5-6 COMM FAILURE
4 LINK PROTECTOR NOT PRESENT 12 LOOP 7-8 COMM FAILURE
5 EVENT BUFFER 80% FULL 13 LOOP 9-10 COMM FAILURE
6 EBI STATUS 14 TEST PROGRAM UPDATE
7 SOFTWARE MISMATCH 15 HISTORY 80% FULL
35033
0 LOOP CONTINUITY TEST FAIL LOOP 1 8 LOOP CONTINUITY TEST FAIL LOOP 9
1 LOOP CONTINUITY TEST FAIL LOOP 2 9 LOOP CONTINUITY TEST FAIL LOOP 10
2 LOOP CONTINUITY TEST FAIL LOOP 3 10 UNPROGRAMMED DEVICE ON LOOP 1
3 LOOP CONTINUITY TEST FAIL LOOP 4 11 UNPROGRAMMED DEVICE ON LOOP 2
4 LOOP CONTINUITY TEST FAIL LOOP 5 12 UNPROGRAMMED DEVICE ON LOOP 3
5 LOOP CONTINUITY TEST FAIL LOOP 6 13 UNPROGRAMMED DEVICE ON LOOP 4
6 LOOP CONTINUITY TEST FAIL LOOP 7 14 UNPROGRAMMED DEVICE ON LOOP 5
7 LOOP CONTINUITY TEST FAIL LOOP 8 15 UNPROGRAMMED DEVICE ON LOOP 6
35034
0 UNPROGRAMMED DEVICE ON LOOP 7 8 IR ENABLED ON LOOP 5
1 UNPROGRAMMED DEVICE ON LOOP 8 9 IR ENABLED ON LOOP 6
2 UNPROGRAMMED DEVICE ON LOOP 9 10 IR ENABLED ON LOOP 7
3 UNPROGRAMMED DEVICE ON LOOP 10 11 IR ENABLED ON LOOP 8
4 IR ENABLED ON LOOP 1 12 IR ENABLED ON LOOP 9
5 IR ENABLED ON LOOP 2 13 IR ENABLED ON LOOP 10
6 IR ENABLED ON LOOP 3 14 TRANSMIT/RECIEVE ERROR ABOVE LIMIT
ON LOOP 1
7 IR ENABLED ON LOOP 4 15 TRANSMIT/RECIEVE ERROR ABOVE LIMIT
ON LOOP 2
35035
0 TRANSMIT/RECIEVE ERROR ABOVE LIMIT ON LOOP 3 8 TOO MANY DEVICES ON LOOP 1
1 TRANSMIT/RECIEVE ERROR ABOVE LIMIT ON LOOP 4 9 TOO MANY DEVICES ON LOOP 2
2 TRANSMIT/RECIEVE ERROR ABOVE LIMIT ON LOOP 5 10 TOO MANY DEVICES ON LOOP 3
3 TRANSMIT/RECIEVE ERROR ABOVE LIMIT ON LOOP 6 11 TOO MANY DEVICES ON LOOP 4
4 TRANSMIT/RECIEVE ERROR ABOVE LIMIT ON LOOP 7 12 TOO MANY DEVICES ON LOOP 5
5 TRANSMIT/RECIEVE ERROR ABOVE LIMIT ON LOOP 8 13 TOO MANY DEVICES ON LOOP 6
6 TRANSMIT/RECIEVE ERROR ABOVE LIMIT ON LOOP 9 14 TOO MANY DEVICES ON LOOP 7
Table E.1 System Troubles Register Map (Continued)
Register Bit No. System Trouble Name Bit No. System Trouble Name
