MODBUS-GW Installation and Operation Manual — P/N LS10015-000NF-E:C2 4/30/2019 55
System Troubles
35035 7 TRANSMIT/RECIEVE ERROR ABOVE LIMIT ON LOOP 10 15 TOO MANY DEVICES ON LOOP 8
35036
0 TOO MANY DEVICES ON LOOP 9 8 MISMATCHED LOOP TYPE ON LOOP 7
1 TOO MANY DEVICES ON LOOP 10 9 MISMATCHED LOOP TYPE ON LOOP 8
2 MISMATCHED LOOP TYPE ON LOOP 1 10 MISMATCHED LOOP TYPE ON LOOP 9
3 MISMATCHED LOOP TYPE ON LOOP 2 11 MISMATCHED LOOP TYPE ON LOOP 10
4 MISMATCHED LOOP TYPE ON LOOP 3 12 Ground Fault Port A
5 MISMATCHED LOOP TYPE ON LOOP 4 13 Ground Fault Port B
6 MISMATCHED LOOP TYPE ON LOOP 5 14 Amplifier Trouble
7 MISMATCHED LOOP TYPE ON LOOP 6 15 AUXIN Trouble
35037
0 DIGIN Trouble 8 ANALOG OUTPUT A TROUBLE
1 FFT TROUBLE 9 ANALOG OUTPUT B TROUBLE
2 REMOTE MIC Trouble 10 ANALOG OUTPUT C TROUBLE
3 DAP Port A Failure 11 ANALOG OUTPUT D TROUBLE
4 DAP Port B Failure 12 FLASH IMAGE ERROR
5 DAL No Answer 13 POWER SUPPLY TROUBLE
6 LOCAL MIC TROUBLE 14 AMPLIFIER LIMIT
7 LOCAL PHONE TROUBLE 15 AMPLIFIER SUPERVISION
35038
0 DAL ADDRESS CONFLICT 8 MAPPING IN PROGRESS LOOP 7
1 DEVICE SERVICING REQUIRED 9 MAPPING IN PROGRESS LOOP 8
2 MAPPING IN PROGRESS LOOP 1 10 MAPPING IN PROGRESS LOOP 9
3 MAPPING IN PROGRESS LOOP 2 11 MAPPING IN PROGRESS LOOP 10
4 MAPPING IN PROGRESS LOOP 3 12 DATABASE CORRUPTED
5 MAPPING IN PROGRESS LOOP 4 13 AUDIO LIBRARY CORRUPTED
6 MAPPING IN PROGRESS LOOP 5 14 DATABASE INCOMPATIBLE
7 MAPPING IN PROGRESS LOOP 6 15 AUDIO LIBRARY INCOMPATIBLE
35039
0 DAL DOWNLOAD IN PROGRESS 8 PRIMARY AMP 1 TROUBLE
1 FIRE VOICE TROUBLE 9 PRIMARY AMP 2 TROUBLE
2 FIRE VOICE NO ANSWER 10 PRIMARY AMP 3 TROUBLE
3 PHONE CHANNEL LIMIT EXCEEDED 11 PRIMARY AMP 4 TROUBLE
4 NCM SMIFFER MODE ACTIVE 12 BACKUP AMP 1 TROUBLE
5 LOCAL CONNECTION LIMIT EXCEEDED 13 BACKUP AMP 2 TROUBLE
6 HARDWARE MISMATCH 14 BACKUP AMP 3 TROUBLE
7 DAL DEVICE NO ANSWER 15 BACKUP AMP 4 TROUBLE
35040
0 DSBUS 1 COMMFAIL 8 Reserved
1 DSBUS 2 COMMFAIL 9 Reserved
2 DSBUS 3 COMMFAIL 10 Reserved
3 DSBUS 4 COMMFAIL 11 Reserved
4 AA TROUBLE BUS FAIL 12 Reserved
5 NFN PAGING CHANNEL LIMIT EXCEEDED 13 Reserved
6 Reserved 14 Reserved
Table E.1 System Troubles Register Map (Continued)
Register Bit No. System Trouble Name Bit No. System Trouble Name
