NFS2-640/E Programming Manual — P/N 52742:L2 7/17/14 35
Basic Program Programming
ACS Selection Group A:
4 Programmable Annunciator #4 See Note
5 Programmable Annunciator #5 See Note
6 Programmable Annunciator #6 See Note
7 Programmable Annunciator #7 See Note
8 Programmable Annunciator #8 See Note
9 Programmable Annunciator #9 See Note
0 Programmable Annunciator #10 See Note
Table 2.13 ACS Selection Groups (2 of 2)
ACS Selection
Group
Annunciator Display Refer to
NOTE: Refer to the VeriFire™ Tools programming utility for programming these annunciators.
Table 2.14 ACS Group A
Point Type Red LED Yellow LED
Switch Function
*
1 Input System Alarm System Trouble Acknowledge
2 Output Not Used Signal Silenced Alarm Silence
3 Output Not Used Program Mode System Reset
4 Output Not Used Supervisory Drill
5 Output NAC #1 Active NAC Trouble Control NAC #1
6 Input Security P/A Maint. Alert Not Used
7 Input Not Used Low Battery Not Used
8 Input Not Used AC Fail Not Used
9 Input Zone 1 Active Zone 1 Trouble Not Used
10 Input Zone 2 Active Zone 2 Trouble Not Used
11 Input Zone 3 Active Zone 3 Trouble Not Used
to to (see note) to (see note)
64 Input Zone 56 Active Zone 56 Trouble Not Used
* Pressing the switch button when the Switch Function is “Not Used” will cause the associated LED to
stop blinking. This is a local acknowledgement at the annunciator only: no message is sent to the panel.
NOTE: Point number to Zone number relationship is sequential. To determine Point to Zone
relationship subtract 8 from Point number to arrive at Zone number.
