36 NFS2-640/E Programming Manual — P/N 52742:L2 7/17/14

Programming Basic Program

ACS Selection Group B:

ACS Selection Group C (SLC #1, Modules 1-64):

Table 2.15 ACS Group B

Point Type Red LED Yellow LED Switch Function*

1 Input Zone 57 Active Zone 57 Trouble Not Used

2 Input Zone 58 Active Zone 58 Trouble Not Used

3 Input Zone 59 Active Zone 59 Trouble Not Used

to to (see note 1) to (see note 1)

43 Input Zone 99 Active Zone 99 Trouble Not Used

44 Output Zone F1 Active Zone F1 Trouble Not Used

45 Output Zone F2 Active Zone F2 Trouble Not Used

to to (see note 2) to (see note 2)

52 Output Zone F9 Active Zone F9 Trouble Not Used

53 Release Ckt #0 Zone R0 Active Zone R0 Trouble Not Used

54 Release Ckt #1 Zone R1 Active Zone R1 Trouble Not Used

to to to (see note 2) to (see note 2)

60 Release Ckt #7 Zone R7 Active Zone R7 Trouble Not Used

61 NAC Output NAC B01 Active NAC B01 Trouble Controls NAC B01

62 NAC Output NAC B02 Active NAC B02 Trouble Controls NAC B02

63 NAC Output NAC B03 Active NAC B03 Trouble Controls NAC B03

64 NAC Output NAC B04 Active NAC B04 Trouble Controls NAC B04

* Pressing the switch button when the Switch Function is “Not Used” will cause the associated LED to stop

blinking. This is a local acknowledgement at the annunciator only: no message is sent to the panel.

NOTE:

1. Point number to Zone number relationship is sequential. To determine Point to Zone

relationship, add 56 to Point number to arrive at Zone number.

2. Point number to Zone number relationship is sequential; therefore, point 48 is zone F5 and

point 57 is zone R4.

Table 2.16 ACS Group C

Point Type Red LED Yellow LED Switch Function

1 Input or Output Module 001 Active Module 001 Trouble Controls Output Module

2 Input or Output Module 002 Active Module 002 Trouble Controls Output Module

3 Input or Output Module 003 Active Module 003 Trouble Controls Output Module

to to (see note) to (see note)

64 Input or Output Module 064 Active Module 064 Trouble Controls Output Module

NOTE: Point number to Module number relationship is sequential; therefore, point 48 is

Module 048.
