NFS2-640/E Programming Manual — P/N 52742:L2 7/17/14 37
Basic Program Programming
ACS Selection Group D (SLC #2, Modules 1-64):
ACS Selection Group E (SLC #1, Modules 65-128):
ACS Selection Group F (SLC #2, Modules 65-128):
ACS Selection Group G (SLC #1 and #2, Modules 129-159):
Table 2.17 ACS Group D
Point Type Red LED Yellow LED Switch Function
1 Input or Output Module 001 Active Module 001 Trouble Controls Output Module
2 Input or Output Module 002 Active Module 002 Trouble Controls Output Module
3 Input or Output Module 003 Active Module 003 Trouble Controls Output Module
to to (see note) to (see note)
64 Input or Output Module 064 Active Module 064 Trouble Controls Output Module
NOTE: Point number to Module number relationship is sequential; therefore, point 48 is
Module 048.
Table 2.18 ACS Group E
Point Type Red LED Yellow LED Switch Function
1 Input or Output Module 065 Active Module 065 Trouble Controls Output Module
2 Input or Output Module 066 Active Module 066 Trouble Controls Output Module
3 Input or Output Module 067 Active Module 067 Trouble Controls Output Module
to to (see note) to (see note)
64 Input or Output Module 128 Active Module 128 Trouble Controls Output Module
NOTE: Point number to Module number relationship is sequential. To determine Point to Module
relationship add 64 to Point number to arrive at Module number.
Table 2.19 ACS Group F
Point Type Red LED Yellow LED Switch Function
1 Input or Output Module 065 Active Module 065 Trouble Controls Output Module
2 Input or Output Module 066 Active Module 066 Trouble Controls Output Module
3 Input or Output Module 067 Active Module 067 Trouble Controls Output Module
to to (see note) to (see note)
64 Input or Output Module 128 Active Module 128 Trouble Controls Output Module
NOTE: Point number to Module number relationship is sequential. To determine Point to Module
relationship add 64 to Point number to arrive at Module number.
Table 2.20 ACS Group G (1 of 2)
Point Type Red LED Yellow LED Switch Function
1 Output SLC 1, Module 129 Active SLC 1, Module 129 Trouble Controls SLC 1, Module 129
2 Output SLC 1, Module 130 Active SLC 1, Module 130 Trouble Controls SLC 1, Module 130
