34 NFS2-640/E Programming Manual — P/N 52742:L2 7/17/14
Programming Basic Program
Annunciation Points
The control panel’s annunciation points are divided into 23 ACS selection groups of 64 points each.
The table below contains a list of these groups, what an annunciator displays when a group is
selected, and where to locate a definition of the 64 points within the group.
Table 2.13 ACS Selection Groups (1 of 2)
ACS Selection
Group
Annunciator Display Refer to
A 8 System points & Zones 1 - 56 Table 2.14 on page 35
B Zones 57 - 99, 9 F Zones, 8 R Zones, 4 NACs Table 2.15 on page 36
C Loop 1, Modules 1 - 64 Table 2.16 on page 36
D Loop 2, Modules 1 - 64 Table 2.17 on page 37
E Loop 1, Modules 65 - 128 Table 2.18 on page 37
F Loop 2, Modules 65 - 128 Table 2.19 on page 37
G Loop 1, Modules 129 - 159 (1 unused point)
Loop 2, Modules 129 - 159 (1 unused point)
Table 2.20 on page 37
H Loop 1, Detectors 1 - 64 Table 2.21 on page 38
I Loop 2, Detectors 1 - 64 Table 2.22 on page 39
J Loop 1, Detectors 65 - 128 Table 2.23 on page 39
K Loop 2, Detectors 65 - 128 Table 2.24 on page 39
L Loop 1, Detectors 129 - 159 (1 unused point)
Loop 2, Detectors 129 - 159 (1 unused point)
Table 2.25 on page 40
M Programmable for use with FireVoice NFV-25/50ZS
or FirstCommand
Table 2.26 on page 41
N 8 System Points & Zones 1-56 “ACS Selection Group N” on
page 41
O 8 System Points & Zones 1-56 “ACS Selection Group O” on
page 41
P* Loop 1, Modules 65-100
Loop 1, Detectors 1-14 (Each detector occupies 2
points)
Table 2.27 on page 42
Q* Loop 2, modules 65-100
Loop 2, Detectors 1-14 (Each detector occupies 2
points)
Table 2.28 on page 43
R* Loop 1, detectors 15-46 (Each detector occupies 2
points)
Table 2.29 on page 44
S* Loop 2, Detectors 15-46 (Each detector occupies 2
points)
Table 2.30 on page 44
T* Loop 1 Detectors 47-78 (Each detector occupies 2
points)
Table 2.31 on page 45
U* Loop 2, Detectors 47-78 (Each detector occupies 2
points)
Table 2.32 on page 45
V* Loop 1, Detectors 79-100 (Each detector occupies 2
points)
Table 2.33 on page 46
W* Loop 2, Detectors 79-100 (Each detector occupies 2
points)
Table 2.34 on page 46
*Group only available with UDACT programmed as option 2.
1 Programmable Annunciator #1 See Note
2 Programmable Annunciator #2 See Note
3 Programmable Annunciator #3 See Note
