86 NFS2-640/E Programming Manual — P/N 52742:L2 7/17/14
Releasing Applications How to Program a Releasing Zone

Example
A programming example of a control module programmed as a Release Form-C circuit for
Releasing Zone R5.
Figure A.17 Control Module Configured as a Release Form-C Circuit
Type Code
REL FORM C
Type Code
REL CIRCUIT
Type Code
REL CIRCUIT
Type Code
REL AUDIBLE
For example, a control module, configured as a Form-C relay,
activates simultaneously with other outputs programmed for R5 (B01,
B02) and the control module with the
REL AUDIBLE Type Code.
Control
Module
B02
B01
Control
Module
R05
Monitor
Module
Detector
Detector
Detector
