Honeywell RT10W User Manual

RT10W Rugged Tablet 63
Far Field Optical System
• Horizontal FOV: 20°
•Vertical FOV: 12°
Note: DPI can be calculated based on the following formula:
Horizontal DPI = 1280 pixels/width of horizontal field of view (inches)
Vertical DPI = 800 pixels/width of vertical field of view (inches)
Port and Connector Pinouts
Docking Connector
Pin Description
1RF_GND
2DOCK_DET#
3GPS ANT
4RF_GND
5RF_GND
6NC
7NC
8DETECT+
9Power
10 Power
11 NC
12 NC
13 GND
14 Power
15 USB+
16 USB-
17 GND
18 GND
19 DETECT-
3
4
1 2
5
6
7
8
9 10
15
16
17
18 19
11 12 13 14
