Page 4 ST 800 SmartLine Pressure Transmitters User’s Manual Revision 10
1.6 Display Options
The ST 800 SmartLine Pressure Transmitter has two display options: Basic and Advanced; see Error! Reference
ource not found..
Table 2 – Available Display Characteristics
Basic Display
ï‚· Suitable for basic process needs
ï‚· 360
o
rotation in 90
o
Increments
ï‚· 2 lines, 16 characters
ï‚· Standard units-of-measurement: Pa, KPa, MPa, KGcm2, TORR, ATM, inH2O,
mH2O, bar, mbar, inHg, FTH2O, mmH2O, MMHG, & PSI
ï‚· Diagnostic messaging
ï‚· Square root output indications
ï‚· Supports optional 3-Button configuration and calibration
Advanced
Display
ï‚· 360
o
rotation in 90
o
increments
ï‚· Three (3) configurable screen formats with configurable rotation timing
o Large process variable (PV)
o PV with bar graph
o PV with trend (1-24 hours, configurable)
ï‚· Eight (8) screens with 3-30 seconds rotation timing
ï‚· Standard and custom engineering units
ï‚· Diagnostic alerts and diagnostic messaging
ï‚· Multiple language support:
o EN, FR, GE, SP, RU, IT & TK
o EN, CH (Kanji), JP
ï‚· Square root output indication
ï‚· Supports 3-button configuration and calibration
ï‚· Supports transmitter messaging, and maintenance mode indications
1.7 Optional 3-Button Assembly
The optional 3-Button Assembly provides the following features and capabilities:
ï‚· Increment, decrement, and enter key functions.
ï‚· With the menu-driven display:
o Comprehensive on-screen menu for navigation.
o Transmitter configuration.
o Transmitter calibration
o Display configuration.
o Set zero and span parameters.
