Revision 10 ST 800 SmartLine Pressure Transmitters User’s Manual Page 73
8 Parts List
8.1 Overview
Individually saleable parts for the various Transmitter models are listed in this section. Some parts are
illustrated for identification. Parts are identified and listed in the corresponding tables as follows:
 Individually saleable parts are indicated in each figure by key number callout.
 Parts that are supplied in kits are indicated in each illustration by key number callout with the
letter K prefix.
Table 21 is a summarized list of recommended spare parts.
Table 21 – Summary List of Recommended Spare Parts
Part Number
Description
Figure No.
Key
No.
1-10
Units
10-
100
Units
100-
1000
Units
Electronics Housing Assembly
50049849-501
50049849-502
50049849-503
50049849-504
50049849-507
50049849-508
HART Electronics Module Without REED
Sensor PWA
HART Electronics Module With REED Sensor
PWA
DE Electronics Module Without REED Sensor
PWA
DE Electronics Module With REED Sensor PWA
FieldBus Electronics Module Without REED
Sensor PWA
FIeldBus Electronics Module With REED Sensor
PWA
Figure 30
5
1
1-2
2-4
51452865-201
51452865-202
51452865-203
51462865-204
Meter Body Seal kit (includes O-rings)
Glass Filled PTFE
VITON
100% PTFE
GRAPHITE
Figure 33 &
Figure 34
K1
1
1-2
2-4
50075472-531
50075472-532
50075472-533
50075472-534
HART/DE Terminal Block Assy Without
Lightning Protection
HART/DE Terminal Block Assy With Lightning
Protection
FieldBus Terminal Block Assy Without Lightning
Protection
FieldBus Terminal Block Assy With Lightning
Protection
Figure 31
3
1
1
1-2
Process head gasket kit
Figure No.
Key
No.
1-10
Units
10-
100
Units
100-
1000
Units
51452868-501
51452868-502
51452868-507
Gasket only, Process Head (12 PTFE packs)
Gasket only, Process Head (6 Viton Head O-
Rings)
Gasket only, Process Head Graphite Gasket
(replacement only for existing graphite gasket)
Figure 33 &
Figure 34
K7
12
12-24
24-48
6
6-12
12-24
6
6-12
12-24
