Page 80 ST 800 SmartLine Pressure Transmitters User’s Manual Revision 10
Table 24 – ST 800 Models STD810, 820, 825, 830 & 870 (Ref. Figure 33)
30753787-001
30753786-001
Drain and Plug Kit, stainless steel
Drain and Plug Kit, Monel
Drain and Plug Kit, Hastelloy C
Each Drain and Plug Kit includes:
51452865-201
51452865-202
51452865-203
51452865-204
Each Meter Body Gasket Kit includes:
Glass Filled PTFE
VITON
100% PTFE
GRAPHITE
O-Ring, Meter Body to Electronics Housing
K7 Process Head Gasket Kits
51452868-502
51452868-507
Gasket only, Process Head (12 PTFE Gaskets/pack)
Gasket only, Process Head (6 Viton Head O-Rings)
Gasket only, Process Head Graphite Gasket (use only as
replacement of existing graphite gasket)
Flange Adapter Gasket Kits
51452868-505
51452868-508
Gasket only, Flange Adapter, 6 PTFE Adapter Gaskets
Gasket only, Flange Adapter, 6 VITON Adapter O-Rings
Gasket only, Flange Adapter Graphite Gasket (use only as
replacement of existing graphite gasket)
½-Inch NPT Flange Adapter Kits
51452867-110
51452867-210
51452867-310
51452867-410
51452867-150
51452867-350
51452867-130
51452867-330
Flange Adapter Kit, with:
SS Flange Adapters and with carbon steel bolts
SS Flange Adapters and with A286 SS (NACE) bolts
SS Flange Adapters and with 316 SS (non-NACE) bolts
SS Flange Adapters and with B7M alloy steel bolts
Monel Flange Adapters and with carbon steel bolts
Monel Flange Adapters and with 316 SS (non-NACE) bolts
Hastelloy C Flange Adapters and with carbon steel bolts
Hastelloy C Flange Adapters and with 316 SS (non-NACE)
bolts
Each 1/2-inch NPT Flange Adapter Kit includes:
1/2-inch NPT Flange Adapter
Bolt, hex head, 7/16-20 UNF, 1.50 inches long
To Next Page
