Revision 10 ST 800 SmartLine Pressure Transmitters User’s Manual Page 41
** “Cal Set C” item in menu will be available only if sensor supports Triple calibration.
Table 13 – Transmitter Setup Menus
<Return> Return to the Level 1 menu
Enter Tag ID name up to 8
characters long. = any
Alphanumeric value
Press to enter
menu selection
and to select
Alphanumeric
to enter and
shift to next
character to the
right.
Selection applies digital
filtering to suppress noise
effects on the PV. The
limits for this value are 0.0
to 32.0 seconds
Disabling sets the loop
output and burnout levels to
the Honeywell levels
Press to enter
menu selection
and to select
from list to enter
Enabling sets the loop
output and burnout levels to
the NAMUR levels
Standard Speed of
Response
The loop output of the
transmitter is a linear
representation of the
differential pressure.
Press to enter
menu selection
and to select
number.
to enter and
shift to next digit
The loop output of the
transmitter represents
%Flow as defined by the
DP Square Root flow
equation.
Allows the user to specify a
single breakpoint as the low
flow cutoff point.
This item is only available
when the Transfer Function
is set to Square Root.
Uses a dual slope formula
to determine the low flow
cutoff point.
This item is only available
when the Transfer Function
is set to Square Root.
Enter the low flow cutoff
point when Single Breakpt
To Next Page
