Page 38 ST 800 SmartLine Pressure Transmitters User’s Manual Revision 10
Table 12 – Calibration Menus
<Return> Return to the Level 1 menu
Set Time
Stamp
<Return>
Hour
# #
These selections allow the
user to enter a time stamp
for the Zero Correct, LRV
Correct, URV Correct, and
Reset Corrects. This time
stamp can be read via
HART and FF
communications.
Press  to enter menu
selection
 and  to select
number.
 to enter and shift to
next digit
 and  to select from
list.
 to enter
Minute
# #
Year
# # # #
Month
January thru
December
Day
# #
Zero
Correct
<Return>
Do Zero Corr.
Executing this selection corrects the Zero
based on the input pressure.
The current live value of the primary
pressure input is shown on this display so
the user can easily see the effect of the
Zero correction.
Press  to enter menu
selection
Scroll to Do Zero Corr.
Press  to initiate
LRV
Correct
<Return>
Do LRV Correct
Executing this selection corrects the LRV
based on the input pressure.
The current live value of the primary
pressure input is shown on this display so
the user can easily see the effect of the
LRV correction.
Press  to enter menu
selection
Scroll to Do LRV Correct
Press  to initiate
URV
Correct
<Return>
Do URV Correct
Executing this selection corrects the URV
based on the input pressure.
The current live value of the primary
pressure input is shown on this display so
the user can easily see the effect of the
URV correction.
Press  to enter menu
selection
Scroll to Do URV
Correct
Press  to initiate
Reset
Corrects
<Return>
Reset Corrects
Executing this selection Resets the Zero,
LRV, and URV Corrects back to Factory
values
Press  to enter menu
selection
Scroll to Reset Corrects
Press  to initiate
