Revision 10 ST 800 SmartLine Pressure Transmitters User’s Manual Page 83
Table 25 – Parts for STG830, 840, 870 and STA822, 840 Transmitter Body (Ref. )
Key
No.
Part Number
Description
Qty/Unit
Process Head Assembly Kits with PTFE Gaskets
51452864-010
51452864-012
51452864-020
51452864-022
51452864-030
51452864-032
51452864-040
51452864-042
51452864-050
51452864-052
Carbon steel head (zinc plated) without side vent/drain
Carbon steel head (zinc plated) with side vent/drain
Stainless steel head without side vent/drain
Stainless steel head with side vent/drain
Hastelloy C head without side vent/drain
Hastelloy C head with side vent/drain
Monel head without side vent/drain
Monel head with side vent/drain
Carbon steel head (nickel plated) without side vent/drain
Carbon steel head (nickel plated) with side vent/drain
Process Head Assembly Kits with PTFE Gaskets
51452864-110
51452864-112
51452864-120
51452864-122
51452864-130
51452864-132
51452864-140
51452864-142
51452864-150
51452864-152
Carbon steel head (zinc plated) without side vent/drain
Carbon steel head (zinc plated) with side vent/drain
Stainless steel head without side vent/drain
Stainless steel head with side vent/drain
Hastelloy C head without side vent/drain
Hastelloy C head with side vent/drain
Monel head without side vent/drain
Monel head with side vent/drain
Carbon steel head (nickel plated) without side vent/drain
Carbon steel head (nickel plated) with side vent/drain
Each process head assembly kit includes:
K1
Pipe Plug (See notes 1 & 2)
1
K2
Vent Plug (See note 1)
1
K3
Vent Bushing (See note 1.)
1
K5
Process Head
1
K6
Gasket (PTFE), Process Head
1
Ka
Gasket (PTFE), Flange Adapter
1
Notes
Note 1: This item is made of the same material as the Process Heads, except for Kits with
carbon steel Process Heads, which include stainless steel Pipe Plug, Vent Plug, and Vent
Bushing.
Note 2: The Kit for Process Heads without side vent/drain does not include Pipe Plugs (K1).
Reference Head
K9
K9
51452951-201
51452951-101
Carbon Steel Blind Reference Head
316 SS Blind Reference Head
1
1
