Honeywell TC500A Integration Guide

12Terminal input/output
Terminal input/output
Table 1: Terminal input/output
Terminal
Point
Name
BACnet Point
Type
BACnet
Object
Instance
ID
Description
UI-1ni_UI1BACnet Numeric
Input
8Universal Input shared to network.
UI2ni_UI2BACnet Numeric
Input
9Universal Input shared to network.
UIO1ni_UIO1BACnet Numeric
Input
10Universal Input shared to network.
no_UIO1BACnet Numeric
Output
64Universal Output shared to network.
UIO2ni_UIO2BACnet Numeric
Input
11Universal Input shared to network.
no_UIO2BACnet Numeric
Output
63Universal Output shared to network.
DO1no_DO1BACnet Boolean
Output
74Digital Output shared to network.
DO2no_DO2BACnet Boolean
Output
75Digital Output shared to network.
DO3no_DO3BACnet Boolean
Output
76Digital Output shared to network.
DO4no_DO4BACnet Boolean
Output
77Digital Output shared to network.
DO5no_DO5BACnet Boolean
Output
78Digital Output shared to network.
DO6no_DO6BACnet Boolean
Output
79Digital Output shared to network.
DO7no_DO7BACnet Boolean
Output
80Digital Output shared to network.
DO8no_DO8BACnet Boolean
Output
81Digital Output shared to network.
