Honeywell TC500A

Space temperature alarm configuration43
Space temperature alarm configuration
Table 24: Space temperature alarm configuration
Key
Options /
Range
Default
Value
BACnet
Point
Type
BACnet
Object
Instance
ID
Description
Cfg_SpcAlarm_TempH
ighLim
100~150
Deg F
125 Deg FBACnet
Numeric
Value
254This is a user configurable point
shown in HMI/Supervisor/ mobile
app which determines the high limit
after which the space temp alarm
will be generated.
Cfg_SpcAlarm_TempL
owLim
0~60 Deg F35 Deg FBACnet
Numeric
Value
255This is a user configurable point
shown in HMI/supervisor/ mobile
app which accepts the low limit
after which the space temp alarm
will be generated.
