Honeywell TC500A Integration Guide

Heat pump configuration27
Heat pump configuration
Table 11: Heat pump configuration
NameRange
Default
Value
BACnet
Point
Type
BACnet
Object
Instance
ID
Description
Cfg_HeatPmp_CngOv
rRelayType
0 = EnergOnCool
1 = EnergOnHeat
ActiveOn
(0)
BACnet
Boolean
Value
13Heat Pump Change Over Relay
- Energize on Cooling (O)
- Energize on Heating (B)
Cfg_HeatPmp_AuxHe
atLockoutSp
30F~120F65°FBACnet
Numeric
Value
50Auxiliary OAT High Heat Lockout
Cfg_HeatPmp_CompL
ockoutSp
0F~70F30°FBACnet
Numeric
Value
51Heat Pump Compressor OAT
Low Lockout
Cfg_HeatPmp_AuxHe
atDroop
0 to 10°F1°FBACnet
Numeric
Value
52Auxiliary Heating Droop
Cfg_HeatPmp_AuxHe
atRampFactor
0.0 to 100.02BACnet
Numeric
Value
53Auxiliary Heating Recovery
Ramp Factor. The heat pump
setpoint recovery ramp is
multiplied by this factor to
determine the auxiliary setpoint
recovery ramp.
Cfg_HeatPmp_Comfo
rtMode
0 = Saving
1 = Comfort
0 (Savings)BACnet
Boolean
Value
14Decides the Auxiliary and
compressor Heating operation
Cfg_HeatPmp_UpStg
Tmr
30~960 Mins0 Mins
(Disabled)
BACnet
Numeric
Value
215Up stage timer value.
