Honeywell TC500A Integration Guide

54User configurable network inputs
User configurable network inputs
Table 27: User configurable network inputs
Key
Options
/ Range
Default
Value
BACnet
Point
Type
BACnet
Object
Instance
ID
Description
ni_ApplicationMode1=Auto
2=Heat
3=Cool
4=Emerg
ency Heat
5=Fan
Only
6=Off
1 = AutoBACnet
ENUM
Value
3Effective application mode from
network. This value wil not be
persisted over power cycle.
ni_ServiceModeEn0=No
Override
1=Service
No
Override
(0)
BACnet
Boolean
Value
6Service Mode network input to
felicitate installer during
commissioning/ maintenance to
shutdown all equipment.
ni_ServiceFan1=Off
2=On (Hi)
3=Low
1=OffBACnet
ENUM
Value
23Fan type configuration network input
when service mode is enabled.
ni_ServiceFanSpeed0-100%0%BACnet
Numeric
Value
85Fan speed configuration network
input when service mode is enabled.
ni_ServiceCompStage10=Cmd
Off
1=Cmd
On
Cmd Off
(0)
BACnet
Boolean
Value
16Compressor Stage 1 configuration
network input when service mode is
enabled.
ni_ServiceCompStage20=Cmd
Off
1=Cmd
On
Cmd Off
(0)
BACnet
Boolean
Value
17Compressor Stage 2 configuration
network input when service mode is
enabled.
ni_ServiceCompStage30=Cmd
Off
1=Cmd
On
Cmd Off
(0)
BACnet
Boolean
Value
18Compressor Stage 3 configuration
network input when service mode is
enabled.
ni_ServiceHeatStage10=Cmd
Off
1=Cmd
On
Cmd Off
(0)
BACnet
Boolean
Value
19Heating Stage 1 configuration
network input when service mode is
enabled.
ni_ServiceHeatStage20=Cmd
Off
1=Cmd
On
Cmd Off
(0)
BACnet
Boolean
Value
20Heating Stage 2 configuration
network input when service mode is
enabled.
ni_ServiceHeatStage30=Cmd
Off
1=Cmd
On
Cmd Off
(0)
BACnet
Boolean
Value
21Heating Stage 3 configuration
network input when service mode is
enabled.
