Honeywell TC500A Integration Guide

22Cooling configuration
Cooling configuration
Table 7: Cooling configuration
NameRange
Default
Value
BACnet
Point Type
BACnet
Object
Instance
ID
Description
Cfg_Cool_CoolType 1 = 1 Stage
2 = 2 Stages
3 = 3 Stages
4 = None
2 (2 Stages)BACnet
ENUM Value
13Cooling Type selection. The
number of compressor
stages used for cooling or
heat pump heating /
cooling stages.
Cfg_Cool_Tr 0 = Auto
1 to 30 ?°F
Auto (0)BACnet
Numeric
Value
41Cooling Throttling Range
Cfg_Cool_It 0 to 5000
seconds
2500
seconds
BACnet
Numeric
Value
42Cooling Integral Time
0 = disable (i.e. proportional
only)
Cfg_Cool_Dt 0 to 3000
seconds
0 secondsBACnet
Numeric
43Cooling Derivative Time
Cfg_Cool_CPH 2 to 20 CPH3 CPHBACnet
Numeric
44Cooling System Response
Cfg_Cool_MinOnTime0 to 300 seconds120 secondsBACnet
Numeric
45Cooling Stage Minimum on
Time
Cfg_Cool_MinOffTime0 to 300 seconds60 secondsBACnet
Numeric
Value
82Cooling Stage Minimum
Off Time
Cfg_Cool_CoolLockou
tSp
-40ºF to 120ºF35°FBACnet
Numeric
Value
46Outside Air Cooling
Lockout Setpoint
Cfg_Cool_DischLoLim
Sp
-40ºF to 60ºF45°FBACnet
Numeric
Value
47Discharge Air Temperature
Low Limit Setpoint.
