Honeywell TC500A Integration Guide

64BACnet object used for alarm
BACnet object used for alarm
Table 30: BACnet object used for alarm
Key
BACnet
Point
Type
BACnet
Object
Instance
ID
PriorityDescription
AlarmPriority_SupplyFanBACnet
Boolean
Output
640 = Nml
1 = High
Priority
Supply Fan Status Mismatch Alarm &
Priority
AlarmPriority_SpaceFreezeProte
ct
BACnet
Boolean
Output
650 = Nml
1 = High
Priority
Space temperature freeze protection
alarm & Priority
AlarmPriority_WaterFlwPrfBACnet
Boolean
Output
660 = Nml
1 = High
Priority
Proof of water flow alarm & Priority
Alarm_UI_SpcTempBACnet
Numeric
Input
12Actual Alarm
point is
AlarmPriority
_TempSens
UI Space Temperature fault detection
point
AlarmPriority_TempSensBACnet
ENUM
Value
131 = Nml
2 = Med
Priority
3 = High
Priority
On Board Temperature Sensor Priority.
High Priority:
1. Only local sensor configured & even if
any one of the on-board temperature
sensor is in alarm
2. Only Remote sensor configured & TR40
sensor connected to sylk addr 2 is giving
null value.
3. configured as multi sensor & both the
remote sensor & on-board configured
sensor has failed.
Medium priority:
1. Configured as Multi sensor & only the
on-board sensor has failed. but getting
reliable value from the sylk sensors.
2. Configured as multi sensor & only one
of the sylk sensor has failed with values
available from other sylk sensors (If
configured) or on-board sensor.
When a valid network temperature is
available, then the high priority alarms will
be considered as medium priority alarm.
Alarm_OnBoardHumSensBACnet
Numeric
Input
2Actual Alarm
point is
AlarmPriority
_HumSens
On Board Humidity Sensor input.
