16
Sylk sensors
Sylk sens
ors
T
able
4:
Sylk sensors
Sy
lk
Address
Use
Name
BA
Cnet
P
oint Type
BACnet
Object
Instance
ID
Description
2
Remote Wall
Module
no_SylkAddr2Temp
BACnet
Numeric Value
223
TR40-H-CO2: Temperature,
Humidity, and/or CO2.
no_SylkAddr2Hum
224
(May also use models TR40,
TR40-H, TR40-CO2, TR40-H-
CO2)
no_SylkAddr2CO2
225
3
Remote Wall
Module
no_SylkAddr3Temp
BACnet
Numeric Value
226
TR40: Temperature
4
Remote Wall
Module
no_SylkAddr4Temp
BACnet
Numeric Value
227
TR40: Temperature
5
Remote Wall
Module
no_SylkAddr5Temp
BACnet
Numeric Value
228
TR40: Temperature
6
Remote Wall
Module
no_SylkAddr6Temp
BACnet
Numeric Value
229
TR120: Temperature and
Humidity
no_SylkAddr6Hum
230
15
17
Table of Contents
default chapter
3
Table of Contents
3
Declaration
5
FCC Part 15 Compliant
5
Waste Electrical and Electronic Equipment (WEEE)
5
Important Safety Information and Installation Precautions
6
Regulation (EC) no 1907/2006
6
Chapter 1 - Introduction
9
About TC500A
9
Scope of the Document
9
Reference Documents
9
Terms, Acronyms, and Abbreviations
10
Chapter 2 - I/O Configuration
11
Terminal Input/Output
12
Terminal Configuration
13
Terminal Input Characteristics Configuration
15
Sylk Sensors
16
Space Temperature & Humidity Sensor Inputs
17
Chapter 3 - Application Configuration
19
Fan Configuration
20
Cooling Configuration
22
Heating Configuration
23
Dehumidification Configuration
25
Humidification Configuration
26
Heat Pump Configuration
27
Filter Configuration
28
Chapter 4 - Common Configuration
29
Equipment Configuration
30
Standby Configuration
30
Control Configuration
31
Multi-Sensor Configuration
32
Occupancy Setpoints Configuration
34
Recovery Setpoint Configuration
35
Demand Shift Setpoints Configuration
36
Thermostat Configurations
37
Sylk Calibration Configuration
39
Sylk Sensor Configuration
41
Alarm Configuration
42
Space Temperature Alarm Configuration
43
Chapter 5 - Configuration Points for Point Sharing
45
Configuration Points for Point Sharing
46
Chapter 6 - Network Inputs
51
User Non-Configurable Network Inputs
52
User Configurable Network Inputs
54
Sylk Sensor Proxy Inputs
56
Chapter 7 - Network Outputs
57
General Network Outputs
58
Chapter 8 - Bacnet Objects for Alarms
63
Bacnet Object Used for Alarm
64
Chapter 9 - Bacnet Guidelines for TC500A
69
Situational Bacnet Guidelines for TC500A
70
