Honeywell TC500A Integration Guide

Terminal input characteristics configuration15
Terminal input characteristics configuration
Table 3: Terminal input characteristics configuration
NameRangeDefault Value
BACnet Point
Type
BACnet
Object
Instance
ID
Description
Cfg_OccSensChk0 = Direct
1 = Reverse
Direct (0)BACnet
Boolean Value
31Occupancy sensor input
characteristics selection
Cfg_DirtyFilterChk0 = Direct
1 = Reverse
Direct (0)BACnet
Boolean Value
32Dirty filter input
characteristics selection
Cfg_AirFlwStsChk0 = Direct
1 = Reverse
Direct (0)BACnet
Boolean Value
33Airflow status input
characteristics selection
Cfg_ShutdownChk0 = Direct
1 = Reverse
Direct (0)BACnet
Boolean Value
34Shutdown input
characteristics selection
Cfg_MASensChk0 = NTC 20K
1 = NTC 10K
NTC 20K (0)BACnet
Boolean Value
137Temperature Sensor
characteristics selection
Cfg_OASensChk0 = NTC 20K
1 = NTC 10K
NTC 20K (0)BACnet
Boolean Value
138Temperature Sensor
characteristics selection
Cfg_DASensChk0 = NTC 20K
1 = NTC 10K
NTC 20K (0)BACnet
Boolean Value
139Temperature Sensor
characteristics selection
Cfg_FiltPresChk0 = 0-5 InWC
1 = 0.2.5 InWC
0-5 InWC (0)BACnet
Boolean Value
155Filter Pressure
Characteristics selection
Cfg_CompCurSen
sMaxAmps
0~9999 Amps10 AmpsBACnet
Numeric Value
220Comp Current Sensor
Maximum Range
Cfg_FanCurSensM
axAmps
0~9999 Amps10 AmpsBACnet
Numeric Value
221Fan Current Sensor
Maximum Range
