Honeywell TC500A Integration Guide

Terminal configuration13
Terminal configuration
Table 2: Terminal configuration
TerminalDefault
BACnet
Point Type
BACnet
Object
Instance
ID
Options
Cfg_UI11 = NoneBACnet
ENUM
Value
241=None, 2=Occupancy Sensor, 3=Dirty Filter, 4=Air Flow
Status, 5=Shutdown, 10 =WtrFlwSts
6=Mixed Air Sensor, 7=Outside Air Sensor, 8=Discharge Air
Sensor, 9=CO2 Sensor, 11=Space Temp Sensor, 12=FiltPres,
13=CompCurSens,14=FanCurSens,15=CompDATemp
Cfg_UI21 = NoneBACnet
ENUM
Value
251=None, 2=Occupancy Sensor, 3=Dirty Filter, 4=Air Flow
Status, 5=Shutdown, 10=WtrFlwSts
6=Mixed Air Sensor, 7=Outside Air Sensor, 8=Discharge Air
Sensor, 9=CO2 Sensor, 11=Space Temp Sensor, 12=FiltPres,
13=CompCurSens,14=FanCurSens,15=CompDATemp
Cfg_UIO11 = NoneBACnet
ENUM
Value
261=None, 2=Occupancy Sensor, 3=Dirty Filter, 4=Air Flow
Status, 5=Shutdown, 11=WtrFlwSts
6=Mixed Air Sensor, 7=Outside Air Sensor, 8=Discharge Air
Sensor, 9=CO2 Sensor, 10=Fan Speed Control, 12=Space
Temp Sensor, 13=OaDmprCtrl, 14=FiltPres,
15=CompCurSens,16=FanCurSens
Cfg_UIO21 = NoneBACnet
ENUM
Value
271=None, 2=Occupancy Sensor, 3=Dirty Filter, 4=Air Flow
Status, 5=Shutdown, 11=WtrFlwSts
6=Mixed Air Sensor, 7=Outside Air Sensor, 8=Discharge Air
Sensor, 9=CO2 Sensor, 10=Heating Control, 12=Space
Temp Sensor, 13=OaDmprCtrl, 14=FiltPres,
15=CompCurSens,16=CompDATemp
Cfg_DO12 = Fan
Command
BACnet
ENUM
Value
281=None, 2=Fan Command, 3=Fan High Speed Command
Cfg_DO22 = Heating
Stage1
Command
BACnet
ENUM
Value
291=None, 2=Heating Stage1 Command
Cfg_DO32 = Heating
Stage2
Command
BACnet
ENUM
Value
301=None, 2=Heating Stage2 Command
Cfg_DO41=NoneBACnet
ENUM
Value
311=None, 2=Heating Stage3 Command 3=Heat Pump
Reversing Valve Command, 4=Fan Low Speed Command,
5=Occupancy Status, 6=Dehumidification Command,
7=Humidification Command
Cfg_DO52 = Cooling /
Compressor
Stage1
Command
BACnet
ENUM
Value
321=None, 2=Cooling / Compressor Stage1 Command
