Honeywell TC500A Integration Guide

20Fan configuration
Fan configuration
Table 6: Fan configuration
NameRange
Default
Value
BACnet
Point Type
BACnet
Object
Instance
ID
Description
Cfg_FanType1 = Single Speed
2 = Two Speed
3 = Variable
Speed
1BACnet
ENUM Value
12Fan can be configured as
single speed, 2 speed or as
a variable speed fan.
Cfg_FanMode1 = Continuous
2 = Auto
3= FanCirculate
1BACnet
ENUM Value
89Fan Mode of operation
config by user & supervisor.
Cfg_FanRunOnCoolDelay0 to 300
seconds.
0BACnet
Numeric
Value
39Fan run on time after all
cooling stages and
economizer stage turns off.
Cfg_FanRunOnHeatDelay0 to 300
seconds
90BACnet
Numeric
Value
40Fan run on time after all
heating stages turns off.
Cfg_FanOnHeat0 = Disable
1 = Enable
1BACnet
Boolean
Value
10Disable: Supply fan
controlled by external duct
thermostat during heat
mode. Enable: Supply fan
controller by digital output
during heat mode.
Cfg_FanCirculate_FanOnT
imePercent
0-100%35%BACnet
Numeric
253When Fan circulate mode is
enabled, based on this
Cfg_FanSpeed_VentMode 1 = Speed1
2 = Speed2
3 = Speed3
4 = Speed4
5 = Speed5
6 = Speed6
1BACnet
ENUM Value
14Fan speed selection for vent
mode.
Cfg_FanSpeed_Comp1Mo
de
1 = Speed1
2 = Speed2
3 = Speed3
4 = Speed4
5 = Speed5
6 = Speed6
1BACnet
ENUM Value
15Fan speed selection for
Compressor/Cooling single
stage mode.
Cfg_FanSpeed_Comp2Mo
de
1 = Speed1
2 = Speed2
3 = Speed3
4 = Speed4
5 = Speed5
6 = Speed6
1BACnet
ENUM Value
16Fan speed selection for
Cooling/Compressor
Multiple Stages.
