Honeywell TC500A Integration Guide

User configurable network inputs55
ni_ServiceHeatCtrl0-100%0%BACnet
Numeric
Value
86Modulating Heating control
configuration network input when
service mode is enabled.
ni_ServiceRevVlvCmd0=Cmd
Off
1=Cmd
On
Cmd Off
(0)
BACnet
Boolean
Value
22Reversing valve configuration
network input when service mode is
enabled.
ni_ServiceSimpleDehCmd0=Cmd
Off
1=Cmd
On
Cmd Off
(0)
BACnet
Boolean
Value
23Dehumudification configuration
network input when service mode is
enabled.
ni_ServiceSimpleHumCmd0=Cmd
Off
1=Cmd
On
Cmd Off
(0)
BACnet
Boolean
Value
24Humidification configuration
network input when service mode is
enabled.
ni_ServiceEconomizerCmd0=Cmd
Off
1=Cmd
On
Cmd Off
(0)
BACnet
Boolean
Value
141Economizer command when service
mode is enabled
ni_ServiceOccStatusCmd0=UnOcc
1=Occ
UnOcc
(0)
BACnet
Boolean
Value
140Occupancy Status command when
service mode is enabled
ni_ServiceOaDmprCtrl0-100%0%BACnet
Numeric
Value
212Outside air damper position when
service mode is enabled.
ni_OccManCom1=Occupi
ed
2=Unocc
upied
3=Bypass
4=Standb
y
5=No
Override
5=No
sOverrid
e
BACnet
ENUM
Value
4Network Occupancy Manual
Override Command.
ni_EmergencyHVACOverrid
e
1=Normal
2=Pressur
ize
3=Depres
surize
4=Purge
5=Shutdo
wn
1=Norm
al
BACnet
ENUM
Value
5Network emergency override to
override the system operation
manually.
Table 27: User configurable network inputs (Continued)
Key
Options
/ Range
Default
Value
BACnet
Point
Type
BACnet
Object
Instance
ID
Description
