Installation and configurati
on
9
Rear panel components
Figure 2-2
HP 16-port Serial Console Server rear panel
1
AC line cord connector—
Connects an AC power
supply.
3
RJ-45 serial console port.
2
RJ-45 port connectors—
Connects serial cabling.
The port number is
adjacent to each
connector.
4
LAN connector—Connects
a 10/100 BaseT interface
cable.
14
