Technical specifications 78
6 Technical specifications
Table 6-1 SCS technical specifications
Item SCS 16 SCS 48
Device ports
Number 16 48
Type Serial ports Serial ports
Connectors Serial port RJ-45 Serial port RJ-45
Console port
Number 1 1
Connector Serial port RJ-45 Serial port RJ-45
Network connection
Number 1 1
Type Ethernet: IEEE 802.3, 10Base T
Fast Ethernet: IEEE 802.3U, 100BaseT
Ethernet: IEEE 802.3, 10Base T
Fast Ethernet: IEEE 802.3U, 100BaseT
Connector RJ-45 RJ-45
Dimensions
H X W X D 4.45 x 22.23 x 20.32cm
1U form factor
(1.75 x 8.75 x 8.00 in.)
4.45 x 44.45 x 25.40 cm
1U form factor
(1.75 x 17.50 x 10.00 in.)
Weight (without cables) 5 lb (2.3 kg) 9 lb (4.08 kg)
Heat dissipation 102 BTU/hr 205 BTU/hr
Airflow 2.5 cfm 14 cfm
Power consumption 30 W 60 W
AC-input power 45 W maximum 90 W maximum
AC-input maximum 100 to 240 VAC 100 to 240 VAC
AC-input current rating 0.5 A 1 A maximum
AC-input cable 18 AWG three-wire cable, with a three-lead IEC-320 receptacle on the power
supply end and a country dependent plug on the power resource end.
Frequency 50 to 60 Hz 50 to 60 Hz
Temperature operating 0° to 40° C
(32° to 104° F)
0° to 40° C
(32° to 104° F)
Temperature nonoperating -20° to +65° C
(-4° to +149° F)
-40° to +70° C
(-40° to +158° F)
Humidity 10% to 90% noncondensing 10% to 90% noncondensing
