HP 16- and 48-Port Serial

Console Servers

Installation Instructions

Read instructions completely before beginning installation procedure.

The information contained herein is subject to change without notice. The only

warranties for HP products and services are set forth in the express warranty

statements accompanying such products and services. Nothing herein should

be construed as constituting an additional warranty. HP shall not be liable for

technical or editorial errors or omissions contained herein.

Part number: 391189-002

Second edition: March 2006

Overview

The HP 16- and 48-Port Serial Console Server (SCS) ships with rack–

mounting hardware for easy integration into the rack. Before

installing the console switches and other components in the rack

cabinet (if not already installed), stabilize the rack in a permanent

location. Begin installing the equipment at the bottom of the rack

cabinet, and then work to the top. Avoid uneven loading or

overloading of the rack cabinets.

Installation checklist

Before installation, See the following lists to be sure that all of the

listed components were received.

Kit contents

• One of the following products:

• One HP 16-Port Serial Console Server (with mounting shelf)

• One HP 48-Port Serial Console Server (with mounting

brackets)

• Power cords

• Mounting hardware (screws, cage nuts, and clip nuts)

• Loopback connector

• Documentation/firmware CD kit

This kit might contain extra hardware for your convenience.

Required tools

• Phillips screwdriver

• T-25 Torx driver
