Menu item Sub-menu item Sub-menu item Values and Description
HTTPS Required: For secure, encrypted
communications, only HTTPS access is accepted. The
print server will appear as a secure site.
HTTP/HTTPS Optional: Access using either HTTP or
HTTPS is permitted.
NOTE: The factory default setting depends
on the print server model.
IPsec or Firewall
NOTE: If the print server supports IPsec,
then IPsec will appear on the menu for both
IPsec or Firewall status. If the print server
does not support IPsec, then Firewall will
appear.
Specify the IPsec or Firewall status on the print server.
Keep: IPsec/Firewall status remains the same as
currently configured.
Disable: IPsec/Firewall operation on the print server is
disabled.
Reset Security Specify whether the current security settings on the
print server will be saved or reset to factory defaults.
No (default): The current security settings are
maintained.
Yes: Security settings are reset to factory defaults.
Diagnostics Embedded Tests (For HP Jetdirect embedded print servers only) This
menu provides tests to help diagnose network
hardware or TCP/IP network connection problems.
Embedded tests help to identify whether a network fault
is internal or external to the device. Use an embedded
test to check hardware and communication paths on
the print server. After you select and enable a test and
set the execution time, you must select Execute to
initiate the test.
Depending on the execution time, a selected test runs
continuously until either the device is turned off, or an
error occurs and a diagnostic page is printed.
LAN HW Test
CAUTION: Running this embedded test will
erase your TCP/IP configuration.
This test performs an internal loopback test. An internal
loopback test will send and receive packets only on the
internal network hardware. There are no external
transmissions on your network.
Yes: Choose this test.
No: Do not choose this test.
HTTP Test This test checks operation of HTTP by retrieving
predefined pages from the device, and tests the
embedded Web server.
Table C-1 Jetdirect EIO Menu on Graphical Control Panel (continued)
174 Appendix C HP Jetdirect Control Panel Menus (V.36.xx) ENWW
