Menu item Sub-menu item Sub-menu item Values and Description
Yes: Choose this test.
No: Do not choose this test.
SNMP Test This test checks operation of SNMP communications
by accessing predefined SNMP objects on the device.
Yes: Choose this test.
No: Do not choose this test.
Data Path Test This test helps to identify data path and corruption
problems on an HP postscript level 3 emulation device.
It sends a predefined PS file to the device, However,
the test is paperless; the file will not print.
Yes: Choose this test.
No: Do not choose this test.
Select All Tests Select this item to run all the embedded tests.
Yes: Run all tests,
No: Do not run all tests.
Execution Time [H] Use this item to specify the length of time (in hours) that
an embedded test will be run. You can select a value
from 1 to 60 hours. If you select zero (0), the test runs
indefinitely until an error occurs or device is turned off.
Data gathered from the HTTP, SNMP, and Data Path
tests is printed after the tests have completed.
Execute No (default): Do not run the selected tests.
Yes: Initiate the selected tests.
Ping Test This test is used to check network communications.
This test sends link-level packets to a remote network
host, then waits for an appropriate response.
Dest Type Specify whether the target device is an IPv4 or IPv6
node.
Dest IPv4 Type the IPv4 address.
Dest IPv6 Type the IPv6 address.
Packet Size Specify the size of each packet, in bytes, to be sent to
the remote host. The minimum is 64 (default) and the
maximum is 2048.
Timeout Specify the length of time, in seconds, to wait for a
response from the remote host. The default is 1 and
the maximum is 100.
Count Specify the number of ping test packets to send for this
test. Select a value from 1 to 100. To configure the test
to run continuously, select 0.
Print Results If the ping test was not set for continuous operation,
you can choose to print the test results.
Yes: Print the test results.
Table C-1 Jetdirect EIO Menu on Graphical Control Panel (continued)
ENWW Jetdirect Menus for Graphical Control Panels 175
