Menu item Sub-menu item Sub-menu item Values and Description
No (default): Results are not printed
Execute Specify whether to initiate the ping test.
No (default): Do not run the test.
Yes: Run the test
Ping Results Use this item to view the ping test status and results
using the control panel display.
Packets Sent Shows the number of packets (0 - 65535) sent to the
remote host since the most recent test was initiated or
completed.
Packets Received Shows the number of packets (0 - 65535) received from
the remote host since the most recent test was initiated
or completed.
Percent Lost Shows the percent of ping test packets that were sent
with no response from the remote host since the most
recent test was initiated or completed.
RTT Min Shows the minimum detected roundtrip- time (RTT),
from 0 to 4096 milliseconds, for packet transmission
and response.
RTT Max Shows the maximum detected roundtrip- time (RTT),
from 0 to 4096 milliseconds, for packet transmission
and response.
RTT Average Shows the average round-trip-time (RTT), from 0 to
4096 milliseconds, for packet transmission and
response.
Ping in Progress Shows whether a ping test is in progress. Yes indicates
a test in progress, and No indicates that a test
completed or was not run.
Refresh When viewing the ping test results, this item updates
the ping test data with current results.
Yes: Update the data.
No: Maintain the existing data. However, a refresh
automatically occurs when the menu times out or you
manually return to the main menu.
Link Speed The link speed and communication mode of the print
server must match the network. The available settings
depend on the device and installed print server. Select
one of the following link configuration settings:
CAUTION: If you change the link setting,
network communications with the print server
and network device might be lost.
Auto (default): The print server uses auto-negotiation
to configure itself with the highest link speed and
communication mode allowed. If auto-negotiation fails,
either 100TX HALF or 10TX HALF is set depending on
the detected link speed of the hub/switch port. (A
1000T half-duplex selection is not supported.)
Table C-1 Jetdirect EIO Menu on Graphical Control Panel (continued)
176 Appendix C HP Jetdirect Control Panel Menus (V.36.xx) ENWW
