System Measurements
Making System Measurements
NOTE
The TV IN connector on the HP
8591C
analyzer with Option 107 is located on the front panel.
However, on HP 8590 E-Series spectrum analyzers with Option 107, the TV IN connector is located on
the rear panel.
Figure
3.3.
Connecting the Cable to the Input Connector
Figure 3-4. Connections for HP 8591 C analyzer with Option 107 (RF Measurements)
Hints
You can return to the system measurements
softkeys
by pressing
C-1,
cm).
3-9
