System Measurements
Creating a Test Plan
Step 2. Select a range of channels (optional)
l.
If ENTER
3Y
RANGE is not displayed, press
[MODE),
CABLE TV ANALYZER , SYSTEM
MEAS
, More
I
of 2 ,
Create
TstPlan
2.
Press ENTER BY RANGE.
3. Enter the number of the first channel in the range of channels you want to
measure. Use the data keys to enter the first channel number, then press
(ENTER).
4. Enter the number of the last channel in the range of channels you want to
measure. Use the data keys to enter the last channel number, then press
@iKq.
5.
After the channel range has been entered, you need to press YES if the
range of channels is scrambled, or press NO if the range of channels is not
scrambled.
NOTE
The scrambled or unscrambled channel status applies to the range of channels that you have just
entered.
6. Select the tests for the range of channels.
l If you want to delete all of the tests, press CLEAR TESTS
’
If you want to select all the tests, press ALL TESTS
l If you want to specify which tests are to be performed, use the data
keys to enter the number of the test, then press
[ENTER).
Repeat this
step for all of the test numbers that you want to select.
3-25
