Figure 5.7. Display Line Delta
To increase the ability to view the DISPLAY LINE DELTA (%> value when it is
obscured by a video signal (as in Figure 5-7) momentarily blank the active
trace. For example, press Trace and then Blank A to view the value.
Then press Clear Write A to reactivate the trace.
When using the delta display line function, if the active function control is
transferred to some other function (for example, Amplitude) or turned off
with Hold , the display line and delta display line must be set up again to
reactivate the delta display line control.
Press (I\I1ODE) twice to return to the cable TV analyzer menu.
