I
-
Channel Measurements Menu Map and
Softkey
Descriptions
Channel Measurements
Softkey
Function Descriptions
3. Sweep time is now the active function, if desired, adjust the sweep time
before continuing the frequency response setup. If sweep time is not
changed, the analyzer uses the default values.
Continue the frequency response setup by selecting FAST SWEEP or
SLOW SWEEP . See Figure 5-l1.
l lf FAST SWEEP is pressed, the analyzer sweeps at the selected sweep
time, or at the 2-second default value.
l If SLOW SWEEP is pressed, the analyzer sweeps at the s-second default
value.
During this setup step, the analyzer converts the reference spectrum
into a reference trace, which
connects the carrier peaks into a
continuous line. When the setup is finished, the conditioned reference
spectrum appears, as shown in Figure 5-12, along with the message
SETUP FINISHED SAVE THIS TRACE.
Hints
A less accurate, but more real-time, response can be obtained by entering a faster sweep time such as
0.1 seconds. This response is more variable for scrambled channels, but still is useful for a quick look.
Experiment to find your own optimum setup.
I
I
5-24
